GW INSTEK Digital Storage Oscilloscopes Model GDS 2302A

SKU: 01GDS2302A

  • Sale
  • Regular price $2,385.00


Features:

  • 300 MHz Bandwidth
  • 2 Input Channels
  • 2 GSa/s Maximum Real-Time Sampling Rate and 100 GSa/s Equivalent Time Sampling Rate
  • 2M points Maximum Record length
  • 8 bits@1M : 1mV~10V Vertical Resolution
  • 1ns/div ~ 100s/div (1-2-5 increments); ROLL: 100ms/div ~ 100s/div Time Base Range
  • 80,000 Waveforms per Second (Max) Waveform Update Rate
  • 8 in. TFT LCD SVGA Color Display (LED Back-light)
  • 800 horizontal x 600 vertical pixels (SVGA) Display Resolution
  • Visual Persistence Oscilloscope (VPO) Technology to Display Less-Frequently-Occurred Signals
  • Fast Update Rate of 80,000 Waveform Per Second
  • Segmented Memory Acquisition and Waveform Search Function
  • 36 Automatic Measurement Functions
  • Standard Model Provides I2C, UART, SPI Serial Bus Trigger and Analysis Functionality
  • Optional 5MHz and 25MHz Function Generator (Not Included)
  • Flexible Remote Control Connectivity (Standard: USB; Optional: LAN/GPIB (Not Included))
  • Upgradable CAN/LIN Bus, DVM, H-Expansion, Data Log and Advanced Logic Functionality (Upgrade Not Included)

Applications:

  • Industrial and Educational R&D Labs
  • Product Testing and Quality Assurance
  • Embedded System and Mix Signal Design
  • System Integration and Debugging
  • Maintenance and Repair Service
