0.96 inch, Resolution: 128 x 64, View angle: > 160°
Support voltage: 3.3V-5V DC, Power consumption: 0.04W during normal operation, full screen lit 0.08W
Embedded Driver IC: SSD1306. Communication: I2C/IIC Interface, only need two I/O ports
Compatible with Arduino Nano, R3 board and Mega, Raspberry pi, 51 MCU, STIM 32, etc.
No backlight is required, and the display unit can be self-luminous. It has ultra-high contrast, bright and clear dots, and it is easy to read even small fonts
There are no fonts embedded in the OLED controller, users can create fonts through font generation software.
Specifications:
OLED self-luminous, no backlight
High resolution: 128x64 (same resolution as 12864, high PPI)
Large viewing angle: greater than 160° (a screen with the largest viewing angle in the display)
Ultra-low power consumption: normal display 0.06w (far lower than TFT display)
Wide voltage power supply (3V~5V), compatible with 3.3V and 5V level logic, no need for level conversion chips
The IIC interface only needs 2 IOs to light up easily
Military-grade process standards, long-term stable work
Provide rich multi-platform routines and provide underlying driver technical support
