Elenco M-2666K Deluxe Full Function Digital Multimeter Kit

SKU: 01DMM2666K

  • Sale
  • Regular price $46.95


A handy portable power supply with a variable output voltage of 15VDC. Mounted in a rugged bakelite case. Do it your self kit form makes a great educational project.

Features:

  • Extra large 1”, 3 1/2 digit display
  • Transistor tester
  • Overload protection
  • Capacitance to 200µF
  • Diode test
  • Audio continuity
  • AC/DC current to 20A
  • Low battery indication
  • Rubber holster
  • Tilt stand
  • Safety input sockets & test leads.
  • Do it your self kit form
  • Makes a great educational project

Specifications:

  • AC + DC Volts: 200mV, 2V, 20V, 200V, 1,000V, 750VAC
  • Accuracy DC: +/-(0.5% rdg + 2dgt)
  • Accuracy DC 1,000V: +/-(0.8% rdg + 2dgt)
  • Accuracy AC 200m, 750V: +/-(1.5% rdg + 2dgt)
  • Accuracy AC 1mV-100mV: +/-(1.0% rdg + 2dgt)
  • Resolution: 100µV
  • AC + DC Current: 200µA, 2mA, 20mA, 200mA, 20A
  • Accuracy DC 200µA-20mA: +(1.5% rdg + 2 dgt)
  • Accuracy DC 200mA: +(2.0% rdg + 2 dgt)
  • Accuracy DC 20A: +(2.5% rdg + 3 dgt)
  • Accuracy AC 200µA-20mA: +(1.0% rdg + 3 dgt)
  • Accuracy AC 200mA: +(1.5% rdg + 3 dgt)
  • Accuracy AC 20A: +(2.0% rdg + 3 dgt)
  • Resolution: 0.1µA
  • Resistance: 200Ω, 2kΩ, 20kΩ, 200kΩ, 2MΩ, 20MΩ
  • Accuracy 200Ω: +(1.0% rdg + 2 dgt)
  • Accuracy 2kΩ - 2MΩ: +(0.8% rdg + 3 dgt)
  • Accuracy 20MΩ: +(2.0% rdg + 4 dgt)
  • Resolution: 0.1O
  • Capacitance: 2nF, 20nF, 200nF, 2µF, 20µF, 200µF
  • Accuracy 2nF - 20µF: +(2.5% rdg + 3 dgt)
  • Accuracy 200µF: +(5.0% rdg + 3 dgt)
  • Resolution: 1pF
  • Size: 7 1/2” (H) x 3 1/2” (W) x 1 13/32” (D)
  • Accessories: Test leads, Manual, 9V Battery included
