GW INSTEK Digital Storage Oscilloscopes Model GDS 3502

SKU: 01GDS3502

  • Sale
  • Regular price $3,355.00

500 MHz, 2 Channels


Visual Persistence Oscilloscope (VPO) technology enables these GDS-3000 series scopes to display waveforms truthfully, while capturing infrequently occurring glitches without missing any waveform info. Software interpolation distortion is also avoided. A unique split-screen feature lets each channel be operated independently with respective settings.


  • Complete set of trigger functions
  • Split screen function
  • Updated software availability from INSTEK website
  • Multi interface support
  • 8" LCD with SVGA (800 x 600) resolution
  • FPGA parallel processing increases speed/update rate
  • Multi-language menu. weight approx 4 kg.
  • Manual, power cord and one-per-channel probe set included
  • Options available at additional charge include various differential, current and passive probes, serial bus analysis and power analysis software
  • GPIB to USB adapter, carry case, and power supplies for current probes. Please inquire for pricing and further info.
