10MHz-1.15GHz Fully Synthesized RF Spectrum Analyzer. Model LPT-2250

Fully synthesized RF spectrum analyzer. User friendly controls. On-screen markers with absolute and relative signal levels for easy measuring. Optional tracking generator for stimulus/response analysis, RF power meter, AM/FM receiver for listening to demodulated signals and remote control for PC control and acquisition.

• Over 1GHz frequency range over a 120 dB range of input level.
• Display span selectable from 0 KHz to 100MHz per division (full span) in standard 2-5-10 step sequence.
• Resolution bandwidth changes automatically as span is changed. 3 KHz, 30KHz, 220KHz, and 4 MHz standard.
• Top of the screen reference level selectable -30dBm to +20dBm adjusts signal for convenient display position.
• Two markers displayed on trace waveform for ease of measurement. Markers may be positioned.
• Frequency and level of these points digitally displayed. Delta marker mode displays difference between markers for simple, fast and accurate relative measurements.
• Digitally synthesized RF system for accuracy and stability. Span and sweep directly based on internal timebase for frequency accuracy at each point along sweep.
• Any factory installed options selected must be done with initial order and cannot be added later

Remote Control Option REM-2250
