Illuminated Push Button - Transparent Cover - Yellow and Green LED

SKU: 17PBA31023

  • Sale
  • $2.15
  • DIP package, SPDT switch, Miniature
  • Smooth travel with distinct click
  • Number of LED: 2
  • LED Color: Yellow and Green
  • Cover: Transparent
  • Body Dimensions: 0.5" x 0.29" x 0.4" (not including pins)
  • 24VDC 50 mA (min. 1µA current acceptable)
  • Initial contact resistance: 20mΩ max (AC 200V, 5mA)
  • Static capacity 1.5 pt max (1 MHz)

Datasheet
