GW Instek

GW Instek GOM-804 DC Milli-Ohm Meter

SKU: 01GOM804

  • Sale
  • Regular price $629.00

The GOM-804 from GW Instek is a DC milli ohm meter with handler/ RS-232C/ USB device. This device has maximum 50000 counts measurement 3.5inch TFT display, rapid sampling rate of 60 readings per second, optimum 0.05% measurement precision, four wire measurement methods as well as the temperature measurement and temperature compensation measurement function to meet the requirement of low resistance measurement application. It also includes 20 sets of panel setting memory and many external control interfaces such as RS-232C, USB, handler/scan/EXT IO. The 3.5inch colour LCD to enhance the clarity of measurement results and to provide display for related setting criteria that tremendously brings up the completeness of test information.


  • 50,000 counts
  • 3.5” (320 x 240) TFT LCD display
  • High accuracy of 0.05% precision
  • 1Amp test current, 0.1µâ„¦ resolution
  • Fast measurement of 60 readings per second
  • Four wire resistance measurement
  • Temperature compensation measurement function
  • Delayed measurement
  • 20 sets of panel setting memory
  • Drive modes (GOM-804) : DC+, Standby
  • Interface: USB device, RS-232C, Handler/Scan/EXT I/O


Box Includes

  • GOM-804 meter
  • Quick start guide x 1
  • Power cord x 1
  • Test lead GTL-308 x 1
  • CD x 1 (complete user manual)
