GW Instek
GW Instek GOM-804G DC Milli-Ohm Meter with GPIB
SKU: 01GOM804G
-
Sale
- Regular price $764.00
- Description
- Specs
Description
The Instek GOM-804G features a 3.5-inch TFT display, maximum 50,000 counts measurement display, the rapid sampling rate of 60 readings per second, optimum 0.05% measurement precision, four wire measurement method as well as the temperature measurement and temperature compensation measurement function to meet the requirement of low resistance measurement application. More features, including 20 sets of panel setting memory and many external control interface such as RS-232C, USB, Handler/Scan/EXT IO or GPIB, greatly elevates the GOM-804 milliohm meter’s convenience on practical applications.
Features
- 50,000 counts
- Plug and play replacement for the GOM-802
- 3.5” (320 x 240) TFT LCD display
- High accuracy of 0.05% precision
- 1 Amp test current, 1µΩ resolution
- Fast measurement of 60 readings per second
- Four wire resistance measurement
- Temperature compensation measurement function
- Delayed measurement
- 20 sets of panel setting memory
- Interface: USB device, RS-232C, Handler/Scan/EXT I/O, and GPIB
Box Includes
- GPIB Functionality
- 1 - User Manual on CD
- 1 - Quick Start Guide
- 1 - Programming Manual
- 1 - Power Cord
- 1 - Output terminal cover
- 1 - Type A-B USB Cable (GTL-246)
- 1 - Analog connector plug set (GTL-308)
- 1 - Chassis connection wire.
